| 型号 | CSD-430L | CSD-490L | CSD-550L | CSD-650L | | 显示参数 |
| | 面板尺寸 | 43" | 49" | 55" | 65" | | 液晶类别 | LED | LED | LED | LED | | 裸机尺寸 | 644×450×1884 | 656×463×1910
| 780×465.7×1950 | 812.4×466.8×1974 | | 包装尺寸 | 822×542×2052 | 862×592×2116 | 982×572×2107 | 1012×585×2140 | | 净重，毛重 | 63.85Kg,103.85Kg | 91.5Kg,127.5Kg | 110Kg,163Kg | 120Kg,177Kg | | 功耗 | ≤180W | ≤250W | ≤280W | ≤300W | | 工作电压 | 110V～240VAC,60/50Hz | 110V～240VAC,60/50Hz | 110V～240VAC,60/50Hz | 110V～240VAC,60/50Hz | | 最佳分辨率 | 1920×1080@60Hz | 1920×1080@60Hz | 1920×1080@60Hz | 1920×1080@60Hz | | 可视角 | 178°,178° | 178°,178° | 178°,178° | 178°,178° | | 亮度 | 380cd/㎡ | 360cd/㎡ | 360cd/㎡ | 360cd/㎡ | | 对比度 | 1000:1 | 1400:1 | 3000:1 | 3000:1 | | 响应时间 | 5ms | 6ms | 8ms | 8ms | | 色彩度 | 16.7M | 16.7M | 16.7M | 16.7M | | 音响配置 | 10W+10W | 10W+10W | 10W+10W | 10W+10W | | 接口 |
| | 广告功能输入 | | SD | / | / | ×1 | ×1 | | LAN interface | / | / | ×1 | ×1 | | USB | / | / | ×2 | ×2 | | SIM | / | / | ×1 | ×1 | | 面板显示功能输入 | | HDMI | ×2 | ×2 | / | / | | VGA | ×1 | ×1 | / | / | | PC AUDIO | ×1 | ×1 | / | / | | COMPONEMT | ×1 | ×1 | / | / | | AV | ×1 | ×1 | / | / | | USB | ×1 | ×1 | / | / | | TV | ×1 | ×1 | / | / | | 输出 | | AV | ×1 | ×1 | / | / |
|
|
